QNAP QVP-85B
8-bay ultra-performance NVR server for SMBs and SOHO


QNAP Products
QVR Pro Series Appliances
QNAP 8 Bay NVR, 8CH (Max Channels: 64), VMS built-in, IP Surveillance, HDMI output for local display
Intel® Core™ i5 6-core/12-thread Processor, 32GB RAM, SATA 6Gb/s, 2 x M.2, 2.5 GbE LAN x 2
#QVP-85B-US
Our Price: $2,199.00

Click here to jump to more pricing!

Package Content

  • QNAP QVP-85B
  • 1 x Power cord
  • 1 x Ethernet cable
  • 24 x Flat head screw (for 3.5″ HDD)
  • 18 x Flat head screw (for 2.5″ HDD)
  • 2 x M.2 SSD Heatsink
  • 2 x Drive tray keys
  • Quick Installation Guide

Overview:

The QVP-85B QVR Pro is a tower-based network surveillance server with an Intel® Core™ multi-core processor that supports eight free IP camera channels and up to sixty-four IP camera channels. Offering an economic and high-performance software and hardware integrated video surveillance solution, the QVP-85B fulfills requirements for secure, reliable, and centrally-managed video surveillance storage for small businesses and offices.



Support ONVIF cameras

Supports thousands of cameras from over 190 brands and ONVIF standards.

Surveillance management

Monitor and manage cameras from Windows®, Mac® and mobile devices.

Storage scalability

Add storage space to the QVP-85B by using QNAP expansion units.


QVP-85B vs. other NAS-based surveillance systems. What’s the difference?

In a conventional NAS-based surveillance system, surveillance is just one of many applications available to users. As all these applications need to share NAS system resources and storage space, surveillance performance could be impacted. The QVP-85B QVR Pro Appliance overcomes this by providing dedicated storage space and reserving full system resources for surveillance, delivering the utmost performance to fulfill professional surveillance system requirements. The QVP-85B also comes with built-in camera channel licenses and essential applications to enable local installation without requiring an internet connection. Simply install the hard drives and power up the QVP-85B to start the installation process.

Features:

High-capacity video surveillance storage solution

QVP-85B is a professional network surveillance server, compatible with 6,000+ IP cameras of 190+ brands and thousands of ONVIF network cameras.

Build a complete surveillance solution with affordable deployment

Live surveillance monitoring, remote management, and smart AI


All-in-one surveillance

Say goodbye to expensive and complicated PC NVR. QNAP network surveillance server integrates QVR Pro software and high-performance hardware.

Direct video playback

QVP-85B has HDMI™ output for direct surveillance video playback, removing the need for a dedicated workstation.

Surveillance failover

Install the high-availability QVR Guard app on another NAS to automatically takeover recording tasks if QVP-85B fails.


Live surveillance video monitoring

Monitor live feeds and receive alert notifications from client applications on PCs or mobiles.

Large-scale central management

Centrally control up to 256 Surveillance NAS (licenses sold separately) in different locations via QVR Center.

AI surveillance event search

Instead of manually searching through a whole day of event videos, QVR Smart Search helps you efficiently search through hundreds of hours of video recordings from hundreds of cameras to find specific events.

MP4 surveillance videos

Videos are saved using the non-proprietary MP4 video format.


Comprehensive camera support and management

The QVP-85B supports thousands of camera models from over 190+ brands with a variety of image formats (including cameras that use ONVIF and RTSP/ HTTP streaming). Even USB webcams are supported, allowing home and budget-conscious users to quickly build surveillance solutions tailored to their environment while providing convenient camera management.


Motion detection using budget-friendly USB webcams

Standard surveillance systems normally only support event recording and notification functions for expensive cameras with integrated motion detection. The QVP-85B provides motion detection even for entry-level cameras and USB webcams. As long as your camera can stream its footage to the QVR Pro appliance (e.g. through RTSP protocol) it supports motion detection, allowing you to build a budget-friendly, motion-detecting surveillance system.


QVR Pro Client

The QVR Pro Client software can be installed on Windows® and Mac® devices, allowing you to monitor from different platforms and flexibly switch from live view or playback mode to take full control over monitored areas.


image-1

Live view and playback

Monitor the live view of multiple channels and play recordings on a single interface. You can also view recordings at a specific time by clicking the timeline or by defining a time range.

image-4

Multiple Notification Methods

The event notification provides multiple ways of being informed of emerging events, including flashing red borders of channels, alert buzzers, and the motion icon on the e-map.


image-3

Qdewarp Technology

The innovative Qdewarp enables users to view standard fisheye camera recordings in proportional ratios and sizes without affecting original recordings. The distorted parts on the edges can be turned into a clear panoramic view.

image-2

Region of Interest

The Region of Interest (ROI) feature allows for viewing multiple regional images from the same camera in live view and playback mode. You can define and enlarge multiple areas to watch the area more closely.


mobile_app

Easy remote monitoring with the QVR Pro Client mobile app

The QVR Pro Client mobile app allows you to remotely monitor multiple channels simultaneously. If your network connection is slow or metered/capped, you can choose the low-bandwidth mode to view a bandwidth-optimized stream without affecting the quality of recordings. In addition, you can remotely set the camera’s preset point or control the PTZ cameras within the app.


Expand your surveillance applications – Control, failover, and facial recognition

QVR Center icon

QVR Center

QVR Pro Control Center

Centrally manage multiple QVR Pro servers installed in different areas. You can also centrally monitor live feeds, play back recordings and receive event notifications from multiple QVR Pro servers, helping you reduce response times to events.

QVR Guard icon

QVR Guard

High-availability Failover Management

Protect QVR Pro from system failure to ensure uninterruptible surveillance recordings. If your QVR Pro fails or crashes, QVR Guard automatically takes over recording tasks, providing dependable redundancy for your surveillance system.

QVR Face icon

QVR Face

Smart facial recognition and analytics

Obtain real-time video analytics from connected cameras and use them to set profiles, groups, and event notifications for instant facial recognition. This is ideal for smart retail, door access management, and VIP welcoming systems.


Smoother surveillance streaming with 2.5GbE connectivity

Connect the two built-in 2.5GbE ports to a QNAP 2.5GbE switch to benefit from a smoother surveillance streaming experience.


Flexible Storage Expansion

Connect TL SATA JBODs: TL-D400S, TL-R400S, TL-D800S, TL-D1600S to expand the storage capacity of the QVP-85B to accommodate data and business growth.


Extend hardware warranty up to 5 years

The QVP-85B is backed by a 3-year warranty at no additional cost. You can also purchase a warranty extension that extends your warranty coverage up to 5 years.

Hardware Specifications:

  QVP-85B
OS QVR Pro OS (QVP)
CPU Intel® Core™ i5 6-core/12-thread Processor
CPU Architecture 64-bit x86
Graphic Processors Intel® HD Graphics 730
Hardware-accelerated Transcoding
System Memory 32 GB SODIMM DDR4 (2 x 16 GB)
Maximum Memory 64 GB ( 2 x 32 GB)
Memory Slot 2 x SO-DIMM DDR4
Flash Memory 5GB (Dual boot OS protection)
Max Live Cameras (Local Display) 56ch @ All 720p,H.264, 30FPS
34ch @ All 1080p,H.264, 30FPS
Max Playback Cameras (Local Display) 16
Max Concurrent Connection (Client) 16 (4 live cameras / per remote client)
*The number of client concurrent connection varies by live cameras
Embedded Channel 8
Max Channel 64
H264 / 1920x1080 / 30FPS
Max Throughput 1686 Mbps
Drive Bay 8 x 3.5-inch SATA 6Gb/s, 3Gb/s
The system is shipped without HDD.
Drive Compatibility 3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable
M.2 SSD Slot 2 x M.2 2280 PCIe Gen4 x4 slots
2.5 Gigabit Ethernet Port 2
PCIe Slot 2
Slot 1: PCIe Gen 4 x16
Slot 2: PCIe Gen 4 x4
USB 3.2 Gen 2 (10Gbps) Port 1 x Type-C USB 3.2 Gen 2 10Gbps
2 x Type-A USB 3.2 Gen 2 10Gbps
HDMI™ Output 1, HDMI™ 1.4b (up to 4096 x 2160 @ 30Hz)
Form Factor Tower
LED Indicators HDD 1-8, Status, LAN, USB port, M.2 port
LCD Display/ Button Yes
Buttons Power, Reset, USB Copy
Dimensions (HxWxD) 7.41 × 12.96 × 11.06 inch
Weight (Net) 16.09 lbs
Operating temperature 0 - 40°C (32°F - 104°F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6°F)
Power Supply Unit 250W, 100-240V
Power Consumption: HDD Sleep Mode 43.131 W
Power Consumption: Operating Mode, Typical 85.701 W
With WD10EFRX drives fully populated
Fan System fan: 2 x 120mm, 12VDC
CPU fan: 1 x 60mm, 12VDC
System Warning Voice prompts or Buzzer
Sound Level 24.2 db(A)
Tray Locker Yes
File System: Internal Hard Drive EXT4
RAID Recovery
Online RAID Capacity Expansion
Online RAID Level Migration
RAID 10+ hot spare
RAID 10
RAID 6+ hot spare
RAID 6
RAID 5+ Spare
RAID 5
RAID 1
JBOD
Single Disk
Global Hot Spare
Wake on LAN (WOL)
Schedule Power On/Off (15 settings)
Telnet & SSH logins (Admin only)
Syslog Server & Client
Language English, German, French, Italian, Spanish, Polish, Swedish, Danish, Norwegian, Finnish, Russian, Japanese, Korean, Dutch, Czech, Traditional Chinese, Simplified Chinese, Turkish, Hungarian, Romanian, Thai, Portuguese/Brazil, Greek

Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications.
Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer/supplier. Any replacement would be fully tested and verified to meet strict compatibility and stability guidelines and will deliver identical performance to the original.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.
