QNAP QVP-41C
4-bay high-performance NVR for SMBs and SOHO
Intel® Celeron J6412 4-core/4-thread Processor, 8GB RAM (Non-expandable), SATA 6Gb/s, 2 x M.2 2280 PCIe Gen 3 x2, 2 x 2.5 GbE LAN, 2 x HDMI 1.4b (up to 4096 x 2160 @ 30Hz)
Our Price: $729.00
Click here to jump to more pricing!
Package Content
- QNAP QVP-41C
- 1 x Power cord
- 1 x Ethernet cable
- AC Adapter
- 2 x Flat head screw (for M.2 SSD)
- 16 x Flat head screw (for 3.5″ HDD)
- 12 x Flat head screw (for 2.5″ HDD)
- 2 x Drive tray keys
- Quick Installation Guide
Overview:
The QVP-41C QVR Pro appliance is a tower-based network surveillance server with an Intel® Celeron® quad-core processor that supports eight free IP camera channels and up to twenty-four IP camera channels. Offering an economic and high-performance software and hardware integrated video surveillance solution, the QVP-41C fulfills requirements for secure, reliable, and centrally-managed video surveillance storage for small businesses and offices.
Support ONVIF cameras
Compatible with thousands of cameras from over 190 brands and ONVIF standards.
Long-term model
The QVP-41C will be available and supported by QNAP for an extended period, up to 2029.
Dual HDMI™ outputs
Play and switch between multi-channel real-time 4K videos on two monitors with extended display.
High-performance NVR
Boost your surveillance data transmission efficiency with dual-port 2.5GbE, a USB 3.2 Gen2 10Gbps port, and 8GB RAM.
RAID protection
Unlike traditional DVR and NVR, the QVP-41C protects your data from drive failure with RAID.
Lightweight AI surveillance applications
QVP-41C incorporates QNAP smart surveillance applications and supports Intel® OpenVINO™ AI engine and Edge TPU expansion via M.2 SSD slots to boost facial recognition performance in QVR Face.
QVP-41C vs. other NAS-based surveillance systems. What’s the difference?
In a conventional NAS-based surveillance system, surveillance is just one of many applications available to users. As all these applications need to share NAS system resources and storage space, surveillance performance could be impacted. The QVP-41C QVR Pro Appliance overcomes this by providing dedicated storage space and reserving full system resources for surveillance, delivering the utmost performance to fulfill professional surveillance system requirements. The QVP-41C also comes with built-in camera channel licenses and essential applications to enable local installation without requiring an internet connection. Simply install the hard drives and power up the QVP-41C to start the installation process.
Features:
High-capacity video surveillance storage solution
QVP-41C is a professional network surveillance server, compatible with 6,000+ IP cameras of 190+ brands and thousands of ONVIF network cameras.
Build a complete surveillance solution with affordable deployment
Live surveillance monitoring, remote management, and smart AI
All-in-one surveillance
Say goodbye to expensive and complicated PC NVR. QNAP network surveillance server integrates QVR Pro software and high-performance hardware.
Dual HDMI™ output for viewing multi-channel videos
Use the dual HDMI™ outputs of QVP-41C for dual-screen extension to play and switch between multi-channel videos on two monitors.
Surveillance failover
Install the high-availability QVR Guard app on another NAS to automatically takeover recording tasks if QVP-41C fails.
Live surveillance video monitoring
Monitor live feeds and receive alert notifications from client applications on PCs or mobiles.
Large-scale central management
Centrally control up to 256 Surveillance NAS (licenses sold separately) in different locations via QVR Center.
AI surveillance event search
Instead of manually searching through a whole day of event videos, QVR Smart Search helps you efficiently search through hundreds of hours of video recordings from hundreds of cameras to find specific events.
MP4 surveillance videos
Videos are saved using the non-proprietary MP4 video format.
Faster facial identification with integrated Intel® OpenVINO™ AI engine.
With integrated Intel® OpenVINO™ AI computing resources, the QVP-41C accelerates AI facial recognition and object identification performance in QVR Face without impacting other applications or services.
Comprehensive camera support and management
The QVP-41C supports thousands of camera models from over 190+ brands with a variety of image formats (including cameras that use ONVIF and RTSP/ HTTP streaming). Even USB webcams are supported, allowing home and budget-conscious users to quickly build surveillance solutions tailored to their environment while providing convenient camera management.
Motion detection using budget-friendly USB webcams
Standard surveillance systems normally only support event recording and notification functions for expensive cameras with integrated motion detection. The QVP-41C provides motion detection even for entry-level cameras and USB webcams. As long as your camera can stream its footage to the QVR Pro appliance (e.g. through RTSP protocol) it supports motion detection, allowing you to build a budget-friendly, motion-detecting surveillance system.
QVR Pro Client
The QVR Pro Client software can be installed on Windows® and Mac® devices, allowing you to monitor from different platforms and flexibly switch from live view or playback mode to take full control over monitored areas.
Live view and playback
Monitor the live view of multiple channels and play recordings on a single interface. You can also view recordings at a specific time by clicking the timeline or by defining a time range.
Multiple Notification Methods
The event notification provides multiple ways of being informed of emerging events, including flashing red borders of channels, alert buzzers, and the motion icon on the e-map.
Qdewarp Technology
The innovative Qdewarp enables users to view standard fisheye camera recordings in proportional ratios and sizes without affecting original recordings. The distorted parts on the edges can be turned into a clear panoramic view.
Region of Interest
The Region of Interest (ROI) feature allows for viewing multiple regional images from the same camera in live view and playback mode. You can define and enlarge multiple areas to watch the area more closely.
Easy remote monitoring with the QVR Pro Client mobile app
The QVR Pro Client mobile app allows you to remotely monitor multiple channels simultaneously. If your network connection is slow or metered/capped, you can choose the low-bandwidth mode to view a bandwidth-optimized stream without affecting the quality of recordings. In addition, you can remotely set the camera’s preset point or control the PTZ cameras within the app.
Expand your surveillance applications – Control, failover, and facial recognition
QVR Center
QVR Pro Control Center
Centrally manage multiple QVR Pro servers installed in different areas. You can also centrally monitor live feeds, play back recordings and receive event notifications from multiple QVR Pro servers, helping you reduce response times to events.
QVR Guard
High-availability Failover Management
Protect QVR Pro from system failure to ensure uninterruptible surveillance recordings. If your QVR Pro fails or crashes, QVR Guard automatically takes over recording tasks, providing dependable redundancy for your surveillance system.
QVR Face
Smart facial recognition and analytics
Obtain real-time video analytics from connected cameras and use them to set profiles, groups, and event notifications for instant facial recognition. This is ideal for smart retail, door access management, and VIP welcoming systems.
Smoother surveillance streaming with 2.5GbE connectivity
Connect the two built-in 2.5GbE ports to a QNAP 2.5GbE switch to benefit from a smoother surveillance streaming experience.
Extend hardware warranty up to 5 years
The QVP-41C is backed by a 3-year warranty at no additional cost. You can also purchase a warranty extension that extends your warranty coverage up to 5 years.
Hardware Specifications:
| QVP-41C | |
|---|---|
| OS | QVR Pro OS (QVP) |
| CPU | Intel® Celeron® J6412 4-core/4-thread processor, burst up to 2.6 GHz |
| CPU Architecture | 64-bit x86 |
| Graphic Processors | Intel® UHD Graphics |
| Hardware-accelerated Transcoding | |
| System Memory | 8GB |
| Maximum Memory | 16 GB ( 2 x 8 GB) |
| Memory Slot | 2 x SO-DIMM DDR4 |
| Flash Memory | 4GB (Dual boot OS protection) |
| Max Live Cameras (Local Display) | 24ch @ All 720p,H.264, 30FPS 12ch @ All 1080p,H.264, 30FPS |
| Max Playback Cameras (Local Display) | 12 |
| Max Concurrent Connection (Client) | 8 (4 live cameras / per remote client) *The number of client concurrent connection varies by live cameras |
| Embedded Channel | 8 |
| Max Channel | 24 H264 / 1920x1080 / 30FPS |
| Max Throughput | 300 Mbps |
| Drive Bay | 4 x 3.5-inch SATA 6Gb/s, 3Gb/s The system is shipped without HDD. |
| Drive Compatibility | 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot-swappable | |
| M.2 SSD Slot | 2 x M.2 2280 PCIe Gen 3 x2 |
| 2.5 Gigabit Ethernet Port | 2 |
| USB 2.0 port | 2 |
| USB 3.2 Gen 2 (10Gbps) Port | 2 |
| HDMI™ Output | 2, HDMI™ 1.4b (up to 4096 x 2160 @ 30Hz) |
| Form Factor | Tower |
| LED Indicators | HDD 1-4, Status, LAN, USB port, M.2 port |
| Buttons | Power, Reset, USB Auto Copy |
| Dimensions (HxWxD) | 6.63 × 6.31 × 8.68 inch |
| Weight (Net) | 4.87 lbs |
| Weight (Gross) | 7.96 lbs |
| Operating temperature | 0 - 40°C (32°F - 104°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6°F) |
| Power Supply Unit | 90W adapter, 100-240V |
| Power Consumption: HDD Sleep Mode | 28.974 W |
| Power Consumption: Operating Mode, Typical | 35.79 W |
| Fan | 1 x 120mm, 12VDC |
| System Warning | Buzzer |
| Sound Level | 16.9 db(A) |
| Tray Locker | Yes |
| File System: Internal Hard Drive | EXT4 |
| RAID Recovery | |
| Online RAID Capacity Expansion | |
| Online RAID Level Migration | |
| RAID 10+ hot spare | |
| RAID 10 | |
| RAID 6 | |
| RAID 5+ Spare | |
| RAID 5 | |
| RAID 1 | |
| RAID 0 | |
| JBOD | |
| Single Disk | |
| Wake on LAN (WOL) | |
| Schedule Power On/Off (15 settings) | |
| Telnet & SSH logins (Admin only) | |
| Syslog Server & Client | |
| Language | English, German, French, Italian, Spanish, Polish, Swedish, Danish, Norwegian, Finnish, Russian, Japanese, Korean, Dutch, Czech, Traditional Chinese, Simplified Chinese, Turkish, Hungarian, Romanian, Thai, Portuguese/Brazil, Greek |
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications.
Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer/supplier. Any replacement would be fully tested and verified to meet strict compatibility and stability guidelines and will deliver identical performance to the original.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.
Pricing Notes:
- Pricing and product availability subject to change without notice.
