Overview:
The QSW-L2110-10T is a Lite Managed switch featuring eight 2.5GbE Base-T ports and two 10GbE Base-T uplink ports. It effectively eliminates bandwidth bottlenecks for Wi-Fi 6/6E/7 APs, NAS, and workstations. Offering VLAN, QoS, and basic traffic management, it provides an affordable and easy-to-maintain 10G backbone upgrade for homes and SMBs. Designed and manufactured in Taiwan, the QSW-L2110-10T delivers reliable, secure, and stable networking quality, making it an ideal choice for businesses.
10GbE High-Speed Network
Flexibly connect to NAS, servers, or uplinks using built-in 10GbE Base-T ports for a high-speed, redundant network architecture.
Office-Friendly Design
The compact, fanless design ensures quiet and space-saving deployment in offices or workspaces without disrupting daily tasks.
Energy-Efficient Operation
IEEE 802.3az (EEE) support automatically adjusts power usage based on network traffic, balancing performance with eco-friendliness.
Easy Web Management
An intuitive Web GUI simplifies daily configuration and network monitoring without adding to your maintenance workload.
Critical Traffic Control
QoS/CoS/DSCP prioritizes smooth VoIP and video streaming, while VLAN allows for efficient departmental network segmentation.
Online Firmware Updates
QSS (QNAP Switch System) supports online firmware checks and Qfinder Pro, enabling one-click updates.
Features:
Smarter Network Management Without Doubling the Budget
Want to avoid networking headaches without complex setups? Lite Managed switches offer the best of both worlds—more control than unmanaged switches and simpler operation than full Layer 2 managed models. Ideal for SMBs, studios, and advanced home users, Lite Managed switches balance practical features, easy configuration, and affordable pricing for optimized high-speed networking.
| Switch Type |
Key Features |
Management Benefits |
Recommended Use Cases |
| Lite Managed |
LACP, VLAN, QoS, Port Mirroring |
Easy traffic control, bandwidth segmentation |
SMBs, retail, basic multi-device segments |
| L2 Managed |
ACL, SNMP, RSTP |
Advanced security and diagnostics |
Virtualization, storage networks, campus backbones |
| Unmanaged |
EEE, Flow Control, Loop Protection |
Plug-and-play, no maintenance |
Homes, small offices, quick meeting room setups |
2.5GbE + 10GbE: Flexibly Build a High-Speed Network Architecture
The QSW-L2110-10T offers a speed combination of 2.5GbE RJ45 and 10GbE RJ45 ports, simultaneously meeting the needs of endpoint access and backbone uplinks. Businesses can flexibly choose based on their devices and application scenarios.
10GbE Uplink Backbone for Smoother Traffic Aggregation
Use 2.5GbE to connect endpoint devices such as Wi-Fi 6/6E/7 APs and workstations, while utilizing 10GbE as an uplink to connect to core switches or server room backbones. This quickly aggregates overall traffic, improving stability and performance for multiple simultaneous users.
10GbE Direct Terminal Connection for Accelerating Critical Devices
When backbone uplink demands are low, the 10GbE ports can be directly connected to critical devices like NAS or servers. This provides an immediate upgrade for high-bandwidth data access while maintaining the overall performance of 2.5GbE endpoint connections.
Highly Cost-Effective 10GbE Upgrade: A Painless Move to a High-Speed Backbone
Integrating 2.5GbE and 10GbE, the QSW-L2110-10T is highly price-competitive compared to switches in the same class, making it especially suitable for users looking to upgrade on a small budget. You can introduce 10GbE to Wi-Fi 6/6E/7 APs, workstations, and NAS while retaining existing wiring and devices, eliminating the need to replace all network equipment at once. This translates limited networking budgets into smoother performance and a longer investment lifespan.
Silent and Reliable with Superior Heat Dissipation
QSW-L2110-10T features a full-metal enclosure for robust protection and excellent thermal performance during high-speed access, ensuring long-term stability. Its fanless design ensures silent operation—ideal for office and studio use. Clear LED indicators make device status easy to monitor.
Optimize network performance with bandwidth and packet control
The QSW-L2110-10T offers practical bandwidth and packet management features that allow efficient bandwidth allocation and network packet grouping, significantly improving overall network performance.
| LACP |
VLAN |
QoS |
IGMP Snooping |
| LACP (Link Aggregation Control Protocol) combines multiple network connections into a single high-speed link, increasing total bandwidth and enabling faster performance. |
VLAN (Virtual LAN) allows flexible segmentation of departmental networks, enabling more efficient and organized traffic management. |
QoS (Quality of Service) manages traffic flow and allocates bandwidth priority to ensure performance-critical applications receive sufficient resources. |
IGMP Snooping manages multicast streams accurately to prevent packet loss or duplication, ensuring smooth and uninterrupted audio/video streaming. |
Intuitive Network Management Interface
The intuitive Web GUI makes network management faster, simpler, and more organized, allowing you to clearly and easily complete daily settings and maintenance.
Overview Dashboard
View real-time system information, port connection status, activation status and traffic usage.
Port Management
View detailed port status, speeds, duplex modes, and configure flow control.
Online firmware check and update
Quickly check for software version updates online and update with a single click to ensure network security.
Extend hardware warranty up to 5 years
The QSW-L2110-10T is backed by a 2-year warranty at no additional cost. You can also purchase a warranty extension that extends your warranty coverage up to 5 years.
Hardware Specifications:
| |
QSW-L2110-10T |
| Management Type |
Lite Managed |
| Number of Ports |
10 |
| 10GbE BASE-T (RJ45) |
2
10G/5G/2.5G/1G/100M |
| 2.5GbE (RJ45) |
8 |
| Power Supply Description |
Adapter |
| Max. Power Consumption |
18W |
| Input Power Type |
DC |
| Input Voltage Range |
12V/1.5A |
| MAC Address Table |
16K |
| Total Non-Blocking Throughput |
40Gbps |
| Switching Capacity |
80Gbps |
| Management Interface |
Web |
| Console |
RJ45 |
| Energy Efficient Ethernet (IEEE 802.3az complaint) |
|
| Fanless |
|
| Supported Standards |
IEEE 802.3 Ethernet
IEEE 802.3u 100BASE-T
IEEE 802.3ab 1000BASE-T
IEEE 802.3bz 2.5G/5GBASE-T
IEEE 802.3an 10GBASE-T
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.1Q VLAN Tagging
IEEE 802.3ad LACP
IEEE 802.1p Class of Service
IEEE 802.3az EEE |
| Form Factor |
Desktop |
| LED Indicators |
Per Port: Speed/Link/Activity
Per System: Power/Loop |
| Buttons |
Reset button |
| Dimensions (HxWxD) |
27 x 240 x 105 mm |
| Weight (Net) |
0.69 kg |
| Weight (Gross) |
0.989 kg |
| Operating Temperature |
0˚C to 40°C (32°F to 104°F) |
| Relative Humidity |
10~95% Non-condensing |
| Certifications |
CE, VCCI, BSMI, FCC, ICES, RCM, UKCA, LVD |
| Electromagnetic Compliance |
CLASS B |
| Jumbo Frames |
12K |
| Warranty |
2 Years |
Note: QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer/supplier. Any replacement would be fully tested and verified to meet strict compatibility and stability guidelines and will deliver identical performance to the original.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.
